Features

Rex Multi-Frequency Pipe & Cable Locator

Rex is Schonstedt’s newest pipe and cable locator, recommended for all underground utilities: water and sewer, electric, telecom, and gas.

Rex is a multi-frequency locator with a price tag comparable to single-frequency locators. The sleek design of the transmitter is less than 2” thick and weighs less than 4 lbs. At slightly over 7 lbs., the entire system fits easily into a custom shoulder bag.

Rex Pipe and Cable Locator use in the field with fire hydrant
Rated IP54 Dust & Water Resistant

Rex Standard Features

  • Ultralight Design: Receiver + Transmitter = Under 7lbs
  • Compact & Portable: Receiver retracts for easy carrying
  • Multi-Frequency Versatility: 512 Hz, 33 kHz and 82 kHz plus 50/60 Hz passive and 512 Hz sonde detection.
  • Schonstedt’s 3-year warranty – Best in the industry.


How Does Rex Stack Up?

A new slim and ultralight transmitter was designed specifically for Rex. Its thin and sleek profile combines with a retractable receiver to make Rex the most user-friendly and portable pipe & cable locator on the market. And best of all, Rex is a multi-frequency locator with a price tag comparable to single-frequency locators.

Specifications

Rex Specifications

Receiver

Operating Frequency:Active: 512 Hz, 33 kHz and 82 kHz
Passive: 50 or 60 Hz
Sonde: 512 Hz
BatteryOne 9V Alkaline single battery
Battery Life:12 hours (intermittent use)
Weight (incl. batteries):2.8 lbs (1.25 kg)
Operating Temp:-4°F to 140°F (-20°C to 70°C)
Water and Dust Resistance:Rated IP54
Dimensions:Closed:
17.5 in (~44 cm)

Extended:
Extended: 27.7 in (~70 cm)
Max. Depth Capability:Approximately 19' (5.8 m)
Sonde mode - approximately 5’ - 15’ (1.5 m to 4.2 m)

Transmitter

Operating Frequency:82kHz, 33kHz & 512 Hz
Operating Modes:Conductive, Inductive, and Inductive Clamp
Max. Output Power:
(Conductive mode @ 1000 Ω load)
512 Hz - 1/2, 1, 2 or 5 W
33 kHz - 1/2, 1, 2 or 5 W
82 kHz - 1/2 or 1
Battery Type:Rechargeable NiMH pack (12V)
Battery Life:8 Hours (intermittent usage @ 70° F)
Charging:Internal Smart Charger powered by AC/DC power adapter
Dimensions10” W x 10.25” D x 1.75” H
(25.4 cm x 26 cm x 4.5 cm)
Weight (incl. batteries):3.5 lbs (1.6 kg)
Operating Temp:-4°F to 140°F (-20°C to 70°C)
Backlighting:White LED array
Water and Dust Resistance:Rated IP54
Standard Equipment

Rex comes with an extensive package of standard equipment including:

  • Receiver & Transmitter
  • Holster (p/n: PC10012)
  • Conductive Clip Assembly (p/n: TM70000) which includes Standard Conductive Clips — C91010 (Red) and C91011 (Black)
  • Soft Shoulder Bag (holds receiver, transmitter, accessories)
  • Ground Stake (p/n: 208263)
  • Power Supply & Cord for Transmitter charging
  • Rex Receiver: 1 – 9V Alkaline Battery (in unit) (p/n: B11013)
  • Rex Transmitter: 1 – Rechargeable NiMH pack (12V) (in unit) (p/n: FD50040)
  • Replacement batteries are available for purchase (p/n: FD50040).



Accessories

Rex Accessories

The following accessories are available for Rex

    • Standard Headset (p/n: XT40000)
    • 3″ Inductive Signal Clamp (p/n: TM60000)
    • 5″ Inductive Signal Clamp (p/n: TM60001)
    • 7″ Inductive Signal Clamp (p/n: TM60002)
    • Large Heavy Duty Clips – p/n: TM70001
    • Small Heavy Duty Clips – p/n: TM70002
    • Sondes:
      • 512 Hz Sonde (p/n: TM50910)
      • 512 Hz Micro Mini Sonde (p/n: TM50911)
